DJI Zenmuse X7 – Cámara DJI con Gimbal de 3-Axis

Categoría:
Tecnología DJI

DJI Zenmuse X7
Cámara DJI
con Gimbal de 3-Axis

Especificaciones del Producto
Compatibilidad

Inspire 2

Sensor

Sensor Size (Still): 23.5×15.7 mm
Sensor Size (Max video recording area): 23.5×12.5 mm
Effective Pixels: 24 MP

Resolución de Fotos

24MP

Resoluciones de Video

CINESSD: CinemaDNG, ProRes
Micro SD: MOV, MP4
Video Resolution Aspect Ratio 17:9

CinemaDNG
6K: 6016×3200, 23.976p, 14-bit
6K: 6016×3200, 24/25/29.97/30p, 12-bit
5.4K: 5440×2880, 23.976/24p, 14-bit
4K DCI: 4096×2160, 23.976p, 14-bit
4K DCI: 4096×2160, 24/25/29.97/30/47.95/48p, 12-bit
3.9K: 3944×2088, 50/59.94p, 12-bit

ProRes RAW
6K: 6016×3200, 23.976p, 14-bit
6K: 6016×3200, 24/25/29.97/30p, 12-bit
5.4K: 5440×2880, 23.976/24p, 14-bit
4K DCI: 4096×2160, 47.95/48p, 12-bit

ProRes RAW HQ
6K: 6016×3200, 23.976p, 14-bit

ProRes
4K DCI: 4096×2160, 23.976/24/25/29.97/30p, 10-bit, HQ
2K: 2048×1080, 47.95/50/59.94p, 10-bit, HQ/XQ

H.264
4K DCI: 4096×2160, 24/25/30/48/50/59.94p

H.265
4K DCI: 4096×2160, 24/25/30p
HD: 1280×720, 24/25/30/48/50/59.94p

Aspect Ratio 16:9

CinemaDNG
6K: 5760×3240, 23.976p, 14-bit
6K: 5760×3240, 24/25/29.97/30p, 12-bit
5.1K: 5120×2880, 23.976/24p, 14-bit
4K Ultra HD: 3840×2160, 23.976p, 14-bit 4K Ultra HD: 3840×2160, 24/25/29.97/30/47.95/48p, 12-bit
3.7K: 3712×2088, 50/59.94, 12-bit

ProRes RAW
6K: 5760×3240, 23.976p, 14-bit
6K: 5760×3240, 24/25/29.97/30p, 12-bit
5.1K: 5120×2880, 23.976/24p, 14-bit
4K Ultra HD: 3840×2160, 47.95/48p, 12-bit

ProRes RAW HQ
6K: 5760×3240, 23.976p, 14-bit

ProRes
4K Ultra HD: 3840×2160, 23.976/24/25/29.97p, 10-bit, HQ/XQ
2.7K: 2704×1520, 47.95/50/59.94p, 10-bit, HQ
FHD:1920×1080, 47.95/50/59.94p, 10-bit, HQ/XQ

H.264
4K Ultra HD: 3840×2160, 24/25/30/48/50/59.94p
2.7K: 2720×1530, 24/25/30/48/50/59.94p
FHD: 1920×1080, 24/25/30/48/50/59.94p
HD: 1280×720, 24/25/30/48/50/59.94p

H.265
4K Ultra HD: 3840×2160, 24/25/30p
2.7K: 2720×1530, 24/25/30/48/50/59.94p
FHD: 1920×1080, 24/25/30/48/50/59.94p

Aspect Ratio 2.44:1

CinemaDNG
5.2K: 5280×2160, 23.976p, 14-bit
5.2K: 5280×2160, 24/25/29.97/30/47.95/48p, 12-bit

ProRes
5.2K: 5280×2160, 23.976/24/25/29.97/30p, 10-bit, HQ

H.264/H.265
4K Ultra HD: 3840×1572, 30p

(FOV will be narrower when shooting at a high frame rate. For more information, please refer to the Zenmuse X7 User Manual.)

ISO

Photo: 100 – 25600
Video: 100 – 1600 (EI mode on); 100 – 6400 (EI mode off)

Temperatura de Operación y Almacenamiento

-4 to 104° F (-20 to 40° C)
-4 to 140° F (-20 to 60° C)

Formatos de Fotos

DJI CINESSD: DNG
Micro SD: DNG, JPEG, DNG+JPEG

Formatos de Video

CINESSD: CinemaDNG, ProRes
Micro SD: MOV, MP4

Dimensiones

151 × 108 × 132 mm

Peso

449 g
